K-660 Truck Refrigeration Unit

K-660 is for larger refrigerated truck box and KingClima directly sell our truck refrigeration units to customers with whole service.

Model: K-660

Driven Type : Vehicle Engine Driven

Application: 20~25m³ truck body

Temperature: -18℃ to +25℃

Discription

Technical Data

Features

INQUIRY

Discription

Brief Introduction of K-660 Truck Freezer Unit

K-660 is for larger refrigerated truck box with 20~25m³size to make temperature controlled from -18℃ to +25℃. For KingClima industry, we directly sell our truck refrigeration units to customers with whole service.

KingClima K-660 Truck Refrigeration System Optional Functions

AC220V/1Ph/50Hz or AC380V/3Ph/50Hz
Optional electric standby system AC 220V/380V

Technical Data

Technical of K-660 Truck Reefer Unit

Model		K-660
Temperature Range(In Container)		-20℃ ~ +30℃ / 0℉ ~ +86℉
Cooling Capacity	0℃/+32℉	5050W / 6745Kcal/h / 18000BTU
Cooling Capacity	-20℃/ 0℉	2890 / 3489Kcal/h / 9980BTU
Compressor	Model	QP16/TM16
	Displacement	163cc/r
	Weight	8.9kg
Condenser	Coil	Copper Tube & Aluminum Fin
	Fan	Two Fans (DC12V/24V)
	Dimensions	1367514365 mm
	Weight	33 kg
Evaporator	Coil	Copper Tube & Aluminum Fin
	Fan	Three Italy Spal Fans(DC12V/24V)
	Air flow	4200m³/h
	Dimensions	1475×649×230 mm
	Weight	34 kg
Voltage		DC12V / DC24V
Refrigerant		R404a/1.7-1.8kg
Defrosting		Hot gas defrosting(Auto./Manual)
Application		20~25m³

Features

Features of K-660 Freezer Unit for Truck

● Multi-function controller with microprocessor control system of truck reefer units
● The units with CPR valve will better protect compressors, especially in extremely hot or cold place.
● Adopt Eco-friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Rooftop mounted unit and slim evaporator design
● Strong refrigeration,cooling fast with short time
● High-strength plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor ,
● Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc.
