KingClima K-260 truck refrigeration units

Truck Refrigeration Units

K-260 Truck Refrigeration Unit

KingClima K-260 Truck refrigeration Units have front mounting and rooftop mounting, driven by vehicle engine and apply for 5-15 m³ Truck body box. The truck refrigeration with chiller and freezing function for transporting fresh fruits, milk ,ice cream ,vegetables, meat, dairy products and seafood…

Driven Type : Vehicle Engine Driven

Cooling Capacity： 1150W(-18℃）, 2015W(0℃）

Application : 6~11m³

Compressor : 5s11/108cc/r

GET QUOTE

Introduction

Technical Data

Features

Application

INQUIRY

Introduction

Brief Introduction of K-260 Small Truck Refrigeration Units for Sale

KingClima K-260 small truck refrigeration units have front mounting and rooftop mounting, driven by vehicle engine and apply for 6-11 m³ Truck body box.

The small truck reefer unis with chiller and freezing function for transporting fresh fruits, milk ,ice cream ,vegetables, meat, dairy products and seafood…

K-260 Small Truck Refrigeration Units Optional Functions

● AC220V/1Ph/50Hz or AC380V/3Ph/50Hz
● Optional electric standby system AC 220V/380V

Technical Data

Model		K-260
Temperature Range in Container		-18℃ ~ +15℃
Temperature Range in Container		0℉ ~ +86℉
Cooling Capacity	0℃/+32℉	2015W
Cooling Capacity	-18℃/ 0℉	1150W
Compressor	Model	5s11
	Displacement	108cc/r
	Weight	8.9 Kg
Condenser	Coil	Aluminum micro-channel parallel flow coils
	Fan	One Fan (DC12V/24V)
	Dimensions	925×430×300 mm
	Weight	26.9 kg
Evaporator	Coil	Copper Tube & Aluminum Fin
	Fan	One Italy Spal Fans (DC12V/24V)
	Dimensions	610550175
	Weight	13.5kg
Voltage		DC12V / DC24V
Air volume		1400m³/h
Refrigerant		R404a/0.8-0.9kg
Defrosting		Hot gas defrosting(Auto./Manual)
Application		6~11m³

Features

K-260 Small Truck Reefer Unit Features

● Multi-function controller with microprocessor control system
● The units with CPR valve will better protect compressors, especially in extremely hot or cold place.
● Adopt Eco-friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Rooftop mounted unit and slim evaporator design
● Strong refrigeration,cooling fast with short time
● High-strength plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor ,
Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc

Application

K-260 is designed for small trucks or pickup trucks reefer units with front mounted types. It is one of hot sale model for refrigerated trucks.

K-260 Truck Refrigeration Units Application
