K-460RS Integrated Battery Drive Truck refrigeration Unit

Introduction

Technical Data

Features

INQUIRY

Introduction

Brief Introduction of K-460S Integrated Battery Drive Van refrigeration Unit :

KingClima is a professional van and truck reefer units suppliers and manufacturer, who can supply all kinds of transport refrigeration system, especially the integrated battery drive truck refrigeration unit . Its standby system and condenser integrate into one piece, it means the electric compressor is in the condenser, and standby system is in the electric compressor.

Compared with the traditional only road truck refrigeration units, the backup power truck refrigeration units for sale has the advantage of easy to installation and more convenient. Customers don’t need to install the standby system under the truck chassis, so the whole refrigeration system looks to be more beautiful, compact and concise,especially used in Norther American market ,such as American ,Canada ,and some South American market.

Technical Data

Technical Data of K-460RS Integrated Battery Drive Truck Refrigeration Unit :

Model		K-460RS
Container temperature		-18℃～+25℃( /Frozen)
Road cooling capacity（W）		4350W（0℃）
		2200W（-18℃）
Standby capacity (W)		4000W（0℃）
		2150W（-18℃）
Container volume(m3)		22m3( 0℃) 16m3(-18℃)
Voltage & Total Current		DC12V(51A) DC24V(30A) AC220V，50HZ，15A
Road Compressor		QP16(162 cc/r)
Standby Compressor （Installed in the Condenser）		THSD456
Refrigerant		R404A 2.0~2.2Kg
Dimensi ons(mm)	Evaporator	1016×655×230
	Condenser With electrical standby	1600×650×605

Notes: 1. Ambient temperature: +38℃ (100℉) for cooling, 0℃ (32℉) for heating; K-value: ≤0.32Watts/m³℃; Recommend box volume in application is related to ambient, refrigerated body K-value and cargoes that will be loaded, etc.
2.Specifications are subject to change without priority notice.

Features

Features of K-460RS Integrated Battery Drive Truck Refrigeration Unit :

● Adopt Eco-friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Easy to install ,the electric standby system is in the internal of condenser, so it can decrease the wire and hose installation.
● Save the volume space to install, small size and pretty appearance
● It has a reliable and stable working function after professional testing in our lab
● Strong refrigeration,cooling fast with short time
● High-strength plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor ,Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc
● Reduce the fuel consumption ,meanwhile save transportation cost when the trucking transport the goods .
● Optional electric standby system AC 220V/380V,more choice for more customer request
● We have two mounting type ,Top roof mounting and Front mounting
