Super1000 Diesel Refrigeration Unit

KingClima Super 1000 is a Self-powered combined diesel engine driven semi-trailer refrigeration unit , it is suitable to transport sensitive cargoes, such as ice cream, frozen or fresh meat, dairy milk,sea food,medical pharmaceutical products and so on. The Super 1000diesel engine powered truck refrigeration system is applied for 25~35m³ truck bodies.
Model: Super 1000
Super 1000: R404a
Cooling capacity(W)(Road): 0oC/8250
Cooling capacity(W)(Standby): 0oC/6820
Introduction
Technical Data
Features
INQUIRY
Introduction

Brief Introduction of Super1000 Diesel Refrigeration Units


KingClima Super1000 freezer unit diesel engine is a Self-powered combined diesel engine driven semi-trailer refrigeration unit , it is suitable to transport sensitive cargoes, such as ice cream, frozen or fresh meat, dairy milk,sea food,medical pharmaceutical products and so on. The Super 1000diesel engine powered truck refrigeration system is applied for 25~35m³ truck bodies.

Technical Data

Super1000 Diesel Powered Truck Refrigeration Unit Technical Data


Model Super 1000
Refrigeratant R404a
Cooling capacity(W)(Road) 0oC/8250
  -20oC/5185
Cooling capacity(W)(Standby) 0oC/6820
  -20oC/4485
Application -internal volume(m3) 35-55
Compressor FK390/385cc
Condenser Dimension L*W*H(mm) 1825*860*630
  Weight(kgs) 475
Air volume m3/h 2550
Evaporator opening dim(mm) 1245*350
Defrost Auto defrost(hot gas defrost)& manual defrost
Voltage DC12V/ 24V
Note: 1. Internal volume is for reference only, it depends on insulation material(Kfator should be equal or lower than 0.32Watts/m2oC), ambient temperature, shipping goods etc.
2. All datum and specifications may change without notice


Main Parts
Of Super1000 Diesel Powered Truck Refrigeration Unit


Mark Name Model&Origin Features Amount
1 Compressor BOCK/Germany centrifugal fan、high efficiency and low noise 1Pcs

2 Condenser fan SPAL(Italy) Brush-less aluminum blade, high efficiency and low noise 1set
3 Evaporator blower SPAL(Italy) axial flow fan 、large air flow and long service life 3set
4 Expansion valve Danfoss easy for installation and mending, with MOP 1set
(Denmark)
5 Filter drier Danfoss high drying and filtering capability 1Pcs
(Denmark)
6 Reservoir KingClima reasonable design,surface coating 1set
7 Pressure switch Hansheng(US) durable ,sensitive and reliable 2set
8 Control panel KingClima controlled by the integrated circuit, easy for handle 1set

Note:
From the date of Availability year , the equipment warranty period is one year after sale. After the warranty expires, we will provide technical support for life.
Features
Our diesel engine truck refrigeration unit have been exported to many countries, such as Peru ,Chile ,Italy ,Spain ,Thailand, Malaysia, Australia, Mexico ,and Middle east area .

● Super series diesel units are multiple temperature refrigeration system for trucks, trailers. The system makes multi temperature zones truck refrigeration come true, which means that Super 1200 reefer unit will provide the ability to deliver both chiller and frozen ones in a single refrigerated truck box, with set points ranging from -20℃ to 30℃.
● All of the diesel powered refrigeration unit for truck have been tested under the 50℃ high ambient temperature and improve its working life.
● The units with CPR valve will better protect compressors, especially in extremely hot or cold place.
● HFC -environment friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Front mounted unit and slim evaporator design,driven by Perkins 3 cylinder engine ,low noise
● Strong refrigeration,axial an ,large air volume,cooling fast with short time
● High-strength ABS plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor ,
 Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc
