Reefer Refrigerated Trailer requires continuous, long-duration operation; consequently, the KF-20 has undergone extensive optimization to ensure exceptional reliability. For instance, all of its core components have been subjected to rigorous fatigue testing to guarantee stable performance—even under conditions involving frequent door openings, extreme summer heat, or rough, long-distance road travel. The condenser’s heat dissipation efficiency has been specially calibrated to maintain effective cooling performance even when exposed to direct sunlight or operating in environments with restricted airflow, thereby preventing overheating-induced shutdowns that could jeopardize cargo safety. This meticulous attention to detail and iterative refinement make the KF-20 a trustworthy, long-term partner for its users.
The performance of the KF-20 Reefer Refrigerated Trailer is equally impressive. Late-night food trucks rely on its quiet operation to coexist harmoniously with nearby residents; early-morning cold-chain delivery vehicles leverage its precise temperature control to keep fresh produce as crisp as if it were just harvested; and temporary outdoor event venues utilize its rapid deployment capabilities to effortlessly resolve the challenge of short-term food storage. It is precisely these seemingly ordinary—yet critically important—moments that collectively establish the KF-20’s sterling reputation among its users. It is more than just a machine; it is a reliable force that safeguards daily livelihoods, preserves the quality of fresh goods, and enhances the overall service experience.
| Models | KC-20 | KF-20 | KF-25 | KF-30 |
| Compressor | WHP05100(33.6ml/rev) | DSH356LV(35.6ml/rev) | 2212GK(34.8ml/rev) | VTH488LS(48.8ml/rev) |
| Cooling Capacity A.T.R U.N. Standard @40°C ambient | 2100W | 3100W | 3100W | 4100W |
| Power consumption | 1340W | 2540W | 2400W | 4260W |
| Refrigerant | R134a/1.5KG | R448a/1.2KG | R404a/1.2KG | R404a/3KG |
| Frequency | AC220V-230V/50HZ/Single phase | AC220V-230V/5 HZ /Single phase | AC/115V/60HZ /Single phase | AC220V-230V/ 60HZ/Three phase |
| Volume supply | 20m³ | 12-15m³ | 12-15m³ | 25m³ |
| Defrosting | 800W | 1980W | 1980W | 2510W |
| Current consumption LRA | 37A | 50A | 37A | 66A |
| Current consumption FLA | 6.1 A | 9.9A | 21A | 9.5A |
| Net Weight | 73Kg | 76Kg | 80Kg | 110Kg |
| Evaporator blower flow rate (@0 static, pressure | 650m³/h | 1100m³/h | 1100m³/h | 2400m³/h |
| Condenser blower flow rate (@0 static, pressure) | 1100m³/h | 1000m³/h | 1000m³/h | 3600m³/h |
| Temperature range | -5°C~10°C | -20°C~10°C | -20°C~10°C | -25°C~-10°C |
| Protection class | 54IP | 54IP | 54IP | 54IP |
