B-350 All Eelctric Van Refrigeration Units

B-350 is rooftop van refrigeration units with high voltage or low voltage for choice to suit for all electric cargo vans with large van box (12-16m³) for lowest temperature controlled with -18℃.

Model: B-350

Voltage: DC48V

Compressor Brand: Two HIGHLY compressors,VDD145 X 2

Refrigerant: R404a

Discription

Technical

Features

Application

INQUIRY

Discription

Brief Introduction of B-350 Refrigeration Units for Electric Van

B-350 is rooftop van refrigeration units with high voltage or low voltage for choice to suit for all electric cargo vans with large van box (12-16m³) for lowest temperature controlled with -18℃.

Technical

Technical of B-350 Electric Van Refrigeration Unit

Model		B-350
Applicable Temperature		-18℃~+15℃
cooling capacity（W）		3070W（0℃） 1560W（-18℃）
Compressor/Number		Two HIGHLY compressors,VDD145 X 2
Voltage (V)		DC48V
Power Range （W）		1500 - 3000 W
Refrigerant		R404a
Refrigerant charge		1.5~1.6 Kg
box temperature adjustment		Electronic digital display
Safety protect		High and low pressure switch
Defrosting		Hot gas defrost automatically
	Evaporator	850×550×175(mm) / 19(Kg)
Dimensions /	Condenser	1000×850×234(mm) / 60(Kg)
Fan Number / Air volume	Evaporator	2个 / 1300m3/h
	Condenser	1个 / 1400m3/h
Box volume(m3)		12m3（-18℃） 16m3（0℃）

Features

◆ Driven by DC powered vehicle battery,save much fuel.
◆ Add CPR valve to protect compressors, suitable for the hot place.
◆ Realize that vehicle engine is off but cooling system is continuous.
◆ Adopt Eco-friendly refrigerant: R404a
◆ Hot gas defrosting system: Auto and manual for choices
◆ Worldwide famous key parts: Sanden compressor, Danfoss Valve, Good Year, Spal fans; Codan, etc.
◆ Compressor is in the inner side of condenser, helps save installation space and easy to install.

Application

Application of B-350 Van Freezer Unit New-energy cargo vans are new trend in nowadays, and the B-350 van reefer units are the good solutions for large full electric cargo vans temperature controlled delivery equipment. It is suitable for 12-16m³van box. Also we have two solutions for our all electric van refrigeration units (B-350 or B-260), customers can use the high voltage units to connect with all electric cargo vans, or can use an external 48V low voltage battery to connect with the units for cooling.

B-350 Refrigeration Units for Electric Van
