Super1200 Diesel Engine Powered Truck Refrigeration System
Super1200 Diesel Engine Powered Truck Refrigeration System
Diesel Engine Units

Super1200 Diesel Refrigeration Unit

The Super 1200 diesel engine powered truck refrigeration system is applied for 50~60 m³ truck bodies.
Model : Super1200
Driven Type : Diesel Engine Driven
Refrigeratant : R404a
Application : 50~60 m³
Introduction
Technical Data
Features
INQUIRY
Introduction
Introduction of Super1200 Diesel Transport Reefer Unit :

Kingthermo Super 1200 is a Self-powered combined diesel engine driven semi-trailer refrigeration unit , it is suitable to transport sensitive cargoes, such as ice cream, frozen or fresh meat, dairy milk,sea food,medical pharmaceutical products and so on. The Super 1200 diesel engine powered truck refrigeration system is applied for 50~60 m³ truck bodies.


Technical Data
Technical Data of Super1200 Diesel Reefer Unit :


Model Super1200
Refrigeratant R404a
Cooling capacity(W)(Road) 0℃/11210
  -200℃/6785
Cooling capacity(W)(Standby) 0℃/8500
  -200℃/6100
Application -internal volume(m3) 50-60

Compressor Germany Bock
Condenser Dimension L*W*H(mm) 1915*970*690
  Weight(kgs) 634
Air volume m3/h 3420
Evaporator opening dim(mm) 1245*350
Defrost Auto defrost(hot gas defrost)& manual defrost
Voltage DC12V/ 24V
Note: 1. Internal volume is for reference only, it depends on insulation material(Kfator should be equal or lower than 0.32Watts/m2oC), ambient temperature, shipping goods etc.
2. All datum and specifications may change without notice
Features

Features of Super1200 Diesel Reefer Unit :

Our diesel truck reefer unit have been exported to many countries, such as Peru ,Chile ,Italy ,Spain ,Thailand, Malaysia, Australia, Mexico ,and Middle east area .

● Super series diesel units are multiple temperature refrigeration system for trucks, trailers. The system makes multi temperature zones truck refrigeration come true, which means that Super 1200 reefer unit will provide the ability to deliver both chiller and frozen ones in a single refrigerated truck box, with set points ranging from -20℃ to 30℃.
● All of the truck refrigeration unit diesel have been tested under the 50℃ high ambient temperature and improve its working life.
● The units with CPR valve will better protect compressors, especially in extremely hot or cold place.
● HFC -environment friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Front mounted unit and slim evaporator design,driven by Perkins 3 cylinder engine ,low noise
● Strong refrigeration,axial an ,large air volume,cooling fast with short time
● High-strength ABS plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor , Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc
